Masonry Magazine October 1969 Page. 13
Data MC AA
Sheet
No. 1
Jordan Marsh Department Store, Braintree, Mass.
Mason Contractor: G. Salvucci Company
All-Weather Program
Raw winter weather can result in many lost man hours as well as substandard work for mason contractors, but G. Salvucci Co., Newton Highlands, Mass., solved these knotty problems with a system of prefabricated polyethylene panels attached to the scaffolding to keep their men working comfortably during the coldest days.
Using the best masons available, only minimal time was lost on the four-story Jordan Marsh Department Store project in Braintree, Mass., despite last winter's biting New England gales, the Salvucci firm reports.
Before cold weather hit, grading, excavation and an access road first were roughed out, and construction utilities completed. Because the design used masonry as a veneer, an early start on the structural steel frame helped to maintain work momentum into winter.
(Please turn page)
Special panel wired to shelf angle of frame
Polyethylene sheet hung from steel floor joists
Heater
Exterior side
14 X 114 Lath
6 Mil Polyethylene
1" X 2" Furring
Interior side
Plywood gusset
Plywood roofing.
Standard panels wired to staging
SECTION
PANEL ELEVATION
Sketch of panel construction created by G. Salvucci Co. for the Jordan Marsh Department Store project in Braintree, Mass. Below, openings are allowed so that various sections of the scaffold can be serviced.
6-7
BUILDING SECTION
Work area is between poly-covered frame and poly sheet. Scaffolding is set on floor for inner wythe construction. Upon completion of inner wythe, interior sheeting is removed and exterior staging erected, covered and roofed over with plywood. Heat is supplied to outer work area through holes left in inner wythe.
masonry • October, 1969
13
