Masonry Cement and Mortar
Masonry cement is a hydraulic cement, that is, it hardens by chemically reacting with water and will do so under water. It consists of portland or blended cement and inorganic plasticizing materials (such as pulverized limestone, hydrated or hydraulic lime) together with other agents introduced to optimize workability, board life and water retention, contribute to improved durability; and reduce drying shrinkage and water absorption of mortar.
Mortar cement is a relatively new product designed for use in demanding structural masonry applications. Mortar cement, like masonry cement, is a hydraulic cement, primarily used to produce masonry mortar. However, mortar cement must meet lower maximum air content limits than masonry cement and is the only mortar material or system that has minimum bond strength requirements.
Whether present as an integral part of masonry cement or as a separate ingredient added at the mixer with hydrated lime, portland cement acts as the glue, which holds the mortar and, ultimately, the masonry, together. Compressive strength and bond strength are related to the portland cement content of mortar.
Hydrated lime may be batched with portland cement, sand, and water at the job site. In this system, lime functions as a plasticizer contributing to workability, board life, and water retention of the mortar.
Either air-entrained portland cement or air-entrained hydrated lime may be used to improve the workability and durability of the portland cement-hydrated lime mortar. However, air-entrained cement and air-entrained lime should not be combined in the same mix.
SELECTION
Once the design loads, type of structure, and masonry units have been determined, the mortar type can be selected. Table 3, adapted from ASTM C 270, provides guidelines for selecting mortar for unreinforced (plain) masonry. It should be remembered that stronger is not necessarily better when selecting mortar for unit masonry. For example, it is not typically necessary to use Type M mortar for high-strength masonry. Type S will provide comparable strength of masonry, and in fact the Masonry Standards Joint Committee's design standard ACI 530/ASCE 5/TMS 402 does not distinguish between the structural properties of masonry constructed using Type S mortar from that constructed using Type M mortar. Moreover, Type S and Type N generally have better workability, board life, and water retention. As a rule of thumb, the specifier should not require use of a mortar of higher compressive strength than necessary to meet structural design criteria.
Unless otherwise indicated, either a masonry cement or cement-lime mortar may be used. Masonry cement mortars, generally offering improved convenience, workability, durability, and uniformity, are used in a majority of masonry construction. For structural masonry, the designer may require Type S cement-lime mortar or mortar cement mortar if the allowable tensile flexural stress values associated with these mortars have been used in the design of the masonry. Codes may also require the use of Type S cement-lime or mortar
