When water penetrates deeply enough to reach structural metal, you've got safety as well as appearance and service-life problems. There are cleaners and conservation treatments which address these problems. But protecting the masonry from water damage to begin with is your best bet.
HOW THEY DID IT IN "THE OLD DAYS"
In the past, architects built to control water penetration and damage. There are three basic stages in the history of wall design. Here's how each dealt with water penetration.
In stage one, thick, load-bearing masonry walls could absorb water. That's because the walls were too thick for water to penetrate all the way through to the building interior. What did penetrate usually evaporated out harmlessly. The masonry could "breathe."
As architects built higher, walls had to become lighter and thinner-no longer load-bearing. Still concerned over water penetration, architects designed cavities behind the masonry facade (stage 2).
Water, penetrating through the cladding, could collect in the cavities to be discharged and dispersed through flashing and weepholes. This design and the previous one both enhanced the masonry's best feature - its natural durability.
Today's rising construction costs force many architects to design more economically. Contemporary barrier-wall design doesn't take water penetration into account (stage 3).
Film Formers
Penetrants
THE ORIGINAL
STEELMATE
VERTICAL REBAR STABILIZER FOR
BLOCK WALL FOUNDATION INSTALLATIONS
Visit Our
Website at
www.steelmate.com
SEEN AT
CONSTRUCTION
TRADE SHOWS
SINCE 1978
BEYOND
Made in 3EATURES:
STEELMATE
TOOL
U.S.A.
-6P Nail Hole for
Solid Anchoring
• Handy View Notch for
Accurate Steel Layout
• 5 Diameters to
Choose From
• Saves Time & Money
• Durable Plastic for
Massive Abuse
• Reusable
Patented in the U.S.A.
Foreign Patents Pending
Call 1-888-STLMATE (1-888-785-6283)
for The Dealer Nearest You
YOUR #1 SOURCE FOR
SOLID SAWN DI-65
SCAFFOLD PLANK
ONE CALL GETS IT ALL!
*OSHA Stamped
*Durable & Strong
*Rodded-Clipped-Branded
*Standard & Special Sizes
*Available Nationwide
*Pocketbook Friendly
KENFOR
1-800-256-7197
PH: 337-625-8141 FX: 337-625-5275
RIC FONTENOT & BOB EDENS
Ext-16
Ext-21
Film-formers cover the masonry pores, blocking water vapor transmission, while penetrants line the pores, letting masonry "breathe." Illustration courtesy of PROSOCO
