PRODUCT
PROFIT
MAKERS
Star Welding Outfit
Smith Welding Equipment, Division of Tescom Corporation, Minneapolis, Minnesota, announces a new combination cutting and welding outfit, called the Star 98. The new 8-piece combination outfit contains torch body, three welding tips, cutting assembly, cutting tip, oxygen regulator and fuel gas regulator.
The torch body included in the Star 98 is a popular Silver Star model which has a 1/32 inch to 1 inch and over welding range. The three copper welding tips feature Smith's exclusive "soft" flame for improved puddle control. The combined welding capacity of the three is 1/16 to 3/8 inch steel.
The Star 98 also includes a Silver Star cutting assembly which has a 6 inch cutting capacity. The cutting tip has replaceable soft seats. Cutting range of the tip is ½ to % inch steel.
The oxygen regulator is a single stage. Provides a 0 to 100 psig delivery pressure range and a maximum inlet pressure of 3000 psig.
For more information, write Smith Welding Equipment, 2633 S. E. Fourth Street. Minneapolis, Minnesota 55414.
Morgen Articulating Boom
The first major change in the design of portable concrete conveyors in recent years is an articulating boom being offered by Morgen Manufacturing Co. on its new model heavy duty conveyor.
The hydraulically controlled boom allows contractors to keep the last 12 feet of the boom parallel with the ground, regardless of boom elevation. This feature extends the cantilever reach beyond the main axle to facilitate the spreading of concrete for roof decks and bridge decks. It also permits lowering the discharge end for more convenient spreading on grade slabs.
The swivel spout at the discharge end of the articulated boom swivels 360 degrees and tilts 90 degrees.
The articulating boom also acts as a folding boom, shortening the conveyor by twelve feet for towing. The feature is available in 48-foot and 56-foot models. The new Morgen heavy duty concrete conveyor is equipped with additional features which make concrete placing a one-man operation. Power steering of the trailing wheels from parallel to the boom to right angles to the boom permits easy movement around the job by one man, and rapid positioning of the conveyor even in tight quarters. The conveyor is self-propelled on the job or between jobs at 8 mph and can be towed without removing the front wheel. The operator's seat is removable and the steering wheel folds out of the way so ready-mix trucks can discharge from either or both sides of the hopper.
Cone rollers automatically train the belt, whether it is running forward or reverse, making it unnecessary to level the undercarriage after every move.
An improved belt wiper is backed by a spring-loaded roller to greatly increase its cleaning ability to prevent carry-back of concrete.
Literature is available from Morgen Manufacturing Co., Box 160, Yankton, S. Dak. 57078.
Massey-Ferguson Forklifts
Massey-Ferguson's line of forklifts includes the MF 2200 (left) and the MF 2500. The MF 2200 is a 4,000 pound lift machine using the basic chassis of the MF 2200 Industrial Tractor; a heavy duty box section frame is attached to the tractor to carry the heavy loads of fork lift work. The MF 2500 is a 6,000 pound lift capacity machine with a massive frame designed as an integral part of the unit; the counterweight is also a part of this integrated design. The fork carriages of both machines are equipped with four guide roller bearings to minimize the side loads on the ball bearing under extreme load conditions. Forks are pivot mounted, and the machines are available with either gas or diesel engines.
Masonry Reinforcing Guide
The most complete line of masonry wall reinforcing available anywhere is described with detailed specifications in the new AA Wire 12-page guide. Correct reinforcing is illustrated for all types of masonry walls-masonry partitions, single wythe and cavity walls, glass block walls, stone, corners, intersections, faced masonry or veneer masonry walls, and anchorage to steel, wood or masonry. This valuable guide is full of facts on reinforcing-from cover to cover an extremely handy tool for all architects, engineers, contractors and building supply companies. New products such as Blok-Trus, Tri-Lok and AA Flex-O-Lok are discussed. Complete information on sizes, finishes and packaging. Send for free copy. AA Wire Products Company, 6100 S. New England Ave., Chicago, Ill. 60638.
Brick Tool Bonanza
The Process Solvent Company, world's largest manufacturer of specialty cleaning products for the construction industry, has announced a Sure Klean $25,000 Brick Tool Bonanza.
Every type of masonry tool from trowels to masonry saws and diamond blades is being offered free during the months of February, March, and April of 1970. General contractors, Mason contractors, tuckpointers, and cleaning contractors are invited to join in the Bonanza.
For complete information and a free copy of the special Sure Klean Brick Tool Bonanza Brochure, write the company direct at 1040 Chelsea Trafficway. Kansas City, Kan. 66104, or contact your nearby Sure Klean distributor located in principal cities throughout the United States.
Good supervision is the art of getting average people to do superior work.
